Meilin Board Production Process

1. Production Process

This product is a high-density board.

During production, all polymer materials are mixed at high speed, generating heat through friction until the temperature exceeds 100°C. Then, the materials are cooled down to below 50°C with water cooling and stirring.

In the extrusion stage, the mixed materials are fed into the production line by a screw blower. They are melted at high temperatures and pushed into the mold by the force of an 80 extruder. The board is then drawn out under high pressure, shaped by water cooling, and finally cut by a cutting machine.

2. Material Composition

Main Ingredients

Inner Mongolia Junzheng Group Resin Powder

Activated Calcium Carbonate Powder 1200 mesh

Ultrafine Activated Carbon Powder

The above are the primary ingredients.

Polymer Material Components

Korean PE wax

AC

NC

German OA3 oxidized polyethylene wax

ACR modifier

Stabilizer

OPE

All the materials listed above are used to manufacture "activated carbon crystalline boards," and the majority are imported raw materials. They are non-toxic and pollution-free.

3. PUR Flat Lamination Process for Decorative Panels

Surface Material

All surfaces of this product are covered with PVC, PP, PET film.

Adhesive Material

The glue we use are import from German.

Construction Process

Construction temperature is around 26°C.

The surface of the body needs to make static electricity and dust removal step, then can cover with the film.

The temperature of the glue should be 135 degree

We apply the film to the sheet using high-temperature roller coating, and then press them together to bond.

Final step is to put the products to cold press machine of 3-7 days to make the film and sheet body more bond.

4. Comparison of Meilin Board Characteristics

High-strength substrate

Oxidation- and weather-resistant surface

Waterproof

Fire-resistant

Moth- and insect-resistant

Laminated using German PUR hot-melt adhesive

Impact-resistant and highly moldable

E0-grade formaldehyde rating

Meilin Board

High Density Activated Carbon Crystal Decorative Board

5mm厚饰面护墙板产品介绍

一、产品名称

5mm厚饰面装饰护墙板

又称：墙面饰面装饰板、环保装饰板

主要用于室内墙体表面装饰，可广泛应用于住宅、酒店、办公空间、商业空间等室内装修领域。

二、产品安装方式

1. 基层处理

施工前需对原始水泥墙面进行处理：

水泥墙面采用石膏板进行打底找平；

确保墙面平整、干燥、无明显凹凸。

2. 板材安装

墙面处理完成后，将护墙板直接粘贴安装；

板材边缘位置可采用文钉枪辅助固定，增强安装稳定性；

板材拼接位置可采用：

金属装饰线条收口；

环保密封胶填充处理。

三、特殊位置处理方式

1. 阳角处理

采用板材开槽工艺：

在板材背面进行精准掏槽；

可直接折弯形成90°阳角；

保持整体效果，美观无明显拼接。

2. 阴角处理

可采用两种方式：

方案一：

板材交错叠加安装。

方案二：

使用专用金属阴角线进行收口处理。

四、产品核心性能

环保性能

✅ 甲醛释放等级：E0级

✅ 室内环保安全，可直接应用于室内空间

防水性能

✅ 板材具有良好的防水性能

✅ 适用于多种室内环境

防火性能

✅ 防火等级：B1级

✅ 满足建筑室内装饰防火要求

五、产品规格尺寸

标准尺寸：

宽度：1220mm

长度：2440mm / 3000mm

定制尺寸：

根据客户需求可进行长度定制：

长度可无限延伸定制生产；

宽度固定。

六、表面装饰材料

支持多种高端饰面：

PVC膜皮

PP膜皮

PET膜皮

可根据不同设计需求选择不同纹理、颜色及表面效果。

七、生产工艺及环保用胶

板膜复合工艺：

采用：

德国胶王品牌 PUR热熔胶

进行板材与饰面膜皮复合。

产品特点：

✅ 国际标准环保胶水

✅ 无溶剂污染

✅ 粘接强度高

✅ 耐热、耐水性能优异

✅ 满足室内直接使用要求

八、产品优势总结

5mm厚饰面护墙板具有：

✔ 超薄轻量化设计

✔ 防水、防火性能优异

✔ E0级环保标准

✔ 多种表面效果选择

✔ 安装快捷方便

✔ 可实现无缝拼接及异形收口

✔ 适用于高端室内装饰工程
